  [Introduction to Xilinx Platform Cable USB G Download Line] Xilinx Platform Cable USB G download line is a high-performance download line for programming and downloading Xilinx FPGA, CPLD and ROM. It is suitable for Xilinx FPGA, CPLD and ROM series chip programming and download debugging, in addition, it can also program SPI interface Flash Prom device; it supports JTAG and slave series download mode, users can flexibly choose configuration mode. Xilinx Platform Cable USB G download line is connected to PC through USB. It does not need external power supply and supports hot plug. The other end connects to development board with different color layouts, which is very convenient to use. The downloader supports windos and Linux systems. Users can use its powerful programming download function in different systems. It can adapt to the target I/O voltage. Its powerful multi-voltage support function can support 5v, 3.3v, 2.5v, 1.8V and 1.5V devices. Its dual-color LED lamp allows users to visually see the connection status between the development board and the downloader. [Xilinx Platform Cable USB G Download Line Features] Xilin Platform Cable G download line can support the programming and configuration of Xilinx FPGA, CPLD and ROM. Support JTAG and slave series configuration mode; Download through cable firmware; Support IMPACT and chipscope; With seamless connection with IMPACT, download clock can be selected in IMPACT to support 12MHZ. Compatible with windows and Linux systems; USB power supply, no external power supply; Connecting with the development board by color marking, the operation is very simple. The power supply status of the target board is indicated by the LED lamp, which makes the user operate more intuitively. Automatic induction and adaptation of target I/O voltage; Provide 5V (TTL), 3.3V (LVCMOS), 2.5V, 1.8V and 1.5V interface voltage; Use industry standards, including JTAG boundary scan IEEE 1149.1 protocol, SPI and USB 2.0; Compatible with full-speed and high-speed USB ports; SPI Flash device can be directly programmed. Support SPI interface flash PROM device programming; [Xilinx Platform Cable USB G Download Wire Device Support] All Virtex FPGA families All Spartan FPGA families XC9500/XC9500XL/XC9500XV CPLDs CoolRunner XPLA3/CoolRunner-II CPLDs XC18V00 ISP PROMs XCF00S/XCF00P Platform Fash PROMs XC4000 series FPGAs SPI flash PROMs [Xilinx Platform Cable USB G Download Line Distribution List] 1. Xilinx Platform Cable USB G downloader; 2. One USB cable; 3. One color label flat line and one download line. 4. Use Instructions Set (English);
