NEW 7" Home Video Intercom Door phone System With 2 White Monitor + 1 Camera 700 TVL Camera, Clearer Video! This Hard-wired Video Door phone Intercom System consists of one 7'' color TFT monitor and one door camera. Upgraded chips are adopted for highly stable performance and it has a nice appearance. It is your perfect choice to use in villas with 700 lines CMOS camera, which can achieve monitoring, dual-way intercom and unlocking. You also can monitor outside image even without people pressing the Monitor button on the Indoor unit. In order to satisfy most of the customers, a complete doorphone system with 5 RFID keyfobs, a push release button have been launched. With this full kit, it will be more convenient to build the full access control system for the home security. You can open the door lock either from indoor or outdoor through several methods.

Features







• With micro-processing technology, auto-remote control, excellent performance and high reliability.

• 7”color TFT LCD. No radiation, low power consumption and high definition. Resolution: 800*480

• Monitor the view out of the door

• Clear night-viewing, 24 hours monitoring, calling, speaking and unlocking remote controlling etc

• The camera could be high definition 1/3" 700TVL line.

• Hands-free intercom

• Brightness, chroma and volume adjustable.

• 16-chord melody rings for option.

• Comes with 5 RFID keyfobs, a push release button switch.

• Supports maximum 500 rfid keyfobs

• Ring cancel function, do not disturb mode.

• Electric lock-control function.

• Max: 3camera+6 monitors, it needs multi-door controller when install 2/3 outdoor units in one system.

•

Details





  It is a door phone which can show you what is going on outside doors on a clearly 7" full color screen of which The Volume, brightness and chroma can be adjusted to meet your need. It can function as a monitor, Press the button of Response/Monitoring, the screen will show you the picture outside doors, which makes you kown the outside world staying in the house.

Specification







Indoor Monitor
LCD Screen	7" TFT
Resolution	800x480
Calling duration	About 120 seconds
Monitor duration	About 60 seconds
Power Consumption	Working: 9W; Standby: 2W
Adapter Input	AC 100-240V, 0.6A, 50/60Hz
Adapter Output	DC 15V, 2000mA
Working Temperature	-35 ~ 50 Celsius
Installation	Wall mounting
Material	PMMA and ABS
Size	240(L) * 150(W) * 26(H)mm
Net Weight	500g
Outdoor Camera
Camera Lens	1/3" CMOS
Resolution	700TVL
illumination	0LUX / F1.2
Night Vision	Visible within 1m
Power Supply	DC 15V, 0.5A
Working Temperature	-10 ~ 50 Celsius
Case	Alunimum panels
Installation	Wall mounting
Size	174(L) *96(W) * 36(H)mm
Net Weight	640g
