Welcome  to  YaoCaixing Electronic store!   1. We are professional  product and sale LED display   2. We are provide low price and high quality on Aliexpress   3. Welcome to our factory for inspection in China       www.ledycx.com       Hope we will be the best business partners

Our Advantage



1.CCC,CE&Rohs,ISO9001,FC,



2.Life span:more than 100000h



3.Excellent after-sales services with free repaire whole life



4.Prompt delivery: 3 working days





Specification





Module Back View
Resolution	64(H)×64(W)
Pitch	2mm
Density	250.000 pixels/m²
LED Arrangement	SMD1515
Driver Mode	32scan(constant current drive)
Size	128mm×128mm
Mask	No mask
Electricity Parameter
Optical Ratings
Brightness	≥1200cd/m²
View Angle	140 degree ( horizontal)  140degree(vertical)
View Distance	2m-200m
Gray Scale	8bits input, correction with 16bits
Display Color	16.7M
Brightness Adjustment	100 levels
Power Supply
Operation Power	AC100-240V 50-60HZ  Switch-able
Maxim Power Consumption	1600 w/m²
Average Power Consumption	800 w/m²
Control System
Correction Scale Level	16bits
Frame Update Frequency	60Hz
Screen Refresh Frequency	1200Hz
Gamma Correction	-5.0—5.0
Support Input	Composite Video, S-Video, DVI, HDMI., SDI, HD_SDI
Control Distance	Ethernet cable 100m, optical fiber 5km
Support VGA Mode	1024×768,1280×1024,1600×1200,1920×1080
Color Temperature	5000-9300 adjustable
Brightness Correction	dot by dot, module by module, cabinet by cabinet
Reliability
Operating Temp.	-20℃ - +60℃  Celsius degree
Operating Humidity	10-95% RH
Operating Life	100,000 hours
MTBF	5000 hours
Continuous Working Time	≥72hours
Protection Level	IP25
Out of Control Pixel Rate	0.01%









Manufacturing flow









Pictures



    Module details       Module testing     Modules aging more than 72 hours   Spot stock (High efficient production workshop to ensure adequate supply)

          About Us



Shenzhen Yao Caixing Electronic Co.,LTD is founded in 2010 which locate in the world LED display manufacturing center-Shenzhen, China. The cover area is about 20000square meters,nearly 400 employees.    We are specialized in the development,production,sales and services of the LED display and focus on providing customers with a full range of product solutions.It is a integrated operation service private enterprise in photoelectric LED display filed.   Several years of study and unremitting efforts,company gathered a large number of talents and has accumulated rich experience.Owned the firstclass automated production equipment and standard production workship.Also established a systematic and professional display screen productionprocess and provide a powerful guarantee for the quanlity of the LED display to improve the the stability and product cost performance.   Main products:Inside or outside SMD full color modules/panels and cabinet display.  Our main production:P1.667,P1.923,P2,P2.5,P3,P3.91,P4,P4.81,P5,P6,P7.62,P10 indoor;                                   P3, P3.91,P4,P4.81,P5,P6,P6.67,PH8,P10,P16 outdoor full color.



Certificate

    Hope you love and choose us ,thanks for your surpport   We'll try to do better and better in the future.   Have a nice day  !!!

 Shenzhen Yao caixing Electronic Co.,LTD



Skype:lining888@hotmail. com   Whats app:+86 13242053456   We chat:13242053456   E-mail :yaocaixing@ledycx. com
