Q series bayonet metal circular connector are made according to Electronic industrial Department standard SJ1744.The wire of pin and socket use solder termination.The plug and receptacle can be mounted with pins or socket.These connectors are small, light,quickly mating and unmating,etc.They are widely used for the electrial connection between instruments,equipments.

Part No Ordering

                           Q    24    J   6   A    J

                          1       2    3   4   5     6

1. Name of series     Q

2.Shell size :            24

3.                            J:Pin, K: Socket

4.Number of contacts:1,2,3,4,6,10,9,26

5. A:Receptacle,without A:Plug

6. J:Au-plated,without J:Ag-plated

Technical characteristics
