DIY RFID Door Waterproof Access Control System Full Kit Set

+ Electric Door Lock + Power Supply + Exit Button + 5 ID Cards + 5 Keyfobs

Full Kit Set ! No Need To Buy Other Accessories !!

Access Control System ! More Safer and More Convenient !!

With this full kit set can set up the company, or authority of office building image standardization management, improve the management level, at the same time, standardized internal management system.

If induction card lost can immediately report the loss in the system, so that even if someone else picked up the induction card can't through the entrance guard system, is more convenient than ordinary mechanical lock, more safety.

Access Control Keypad:

The W1 is single door multifunction standalone Waterproof access controller or a Wiegand output keypad or card reader. It is suitable for mounting either indoor or outdoor in harsh environments. It is housed in s strong, sturdy and vandal proof zinc alloy electroplated case.

These features make W1 an ideal choice for door access not only for small shops and domestic households but also for commercial and industrial applications such as factories, warehouses, laboratories, banks and prisons.

• Metal shell, anti-vandal, more secure, waterproof design.
• Waterproof, can working outside.
• Backlight keypad.
• Convenient for operating on night.
• Large Capacity: 2,000 users.
• Support 3 Modes Access: Card, PIN, Card+PIN.
• Card Type: 125KHz EM, PIN length: 4~8 digits.
• Very low power consumption ( ≤35mA), long service life and stable performance.
• High Speed Search: filled with 2,000 users, the search time < 0.1 seconds.
• Manage cards: the manage cards can add/delete the users directly, very convenient
• Wiegand 26 input & output, can work as Wiegand reader/Controller.
• Protective properties: IP65 fully-potted. with anti-demolition, alarm function, anti-static interference 12KV.
• Certificate: CE

Specification:

• Operating Voltage: 12~18V AC/12~24V DC
• Adjustable Door Relay Time: 0~99s
• Static Current: ≤35mA
• Wiegand Interface: Wiegand 26
• Card Read Rang: 3~6cm
• Operating Temperature: -40°c~60°c
• Operating Humidity: 0%~95%
• Lock Output Load: ≤1A
• Alarm Output Load: ≤3A
• Antistatic: 12KV
• Environment: Conforms to IP65
• Wiring Length: 90~100CM
• Signal Light: red, green, yellow LED light display
• Dimensions: L 135mm×W58mm×H 26mm

Power Supply:

This AC110V--240V Power supply controller is a transformer which provides stable output voltage for access controller,door lock (smart lock, magnetic lock, electromagnetic lock, electrical lock, electric bolt lock, mortice lock) , remote control and exit button. Can used all over the world.

• Can reduce the load of access controller, save wiring to reduce the hidden trouble
• Set NC / NO outputs, can control various types of electric locks
• Based delay control circuit, lock time can be in 0-15 seconds
• The circuit board has remote control port.

• Input Voltage: AC 110~220V  50~60Hz
• Output Voltage: DC 12V 3A
• Outer Dimensions: 103 x 68 x 33mm

• NC Mode - (Locked while supplied with power) Unlock Safe Mode;
• Made of Stainless Steel;
• Performance Testing: 1000000 times aging test;
• Authority Certification: CE & MA Approved.

Specification:

• Application: wood/iron doors;
• Working Voltage: 12VDC
• Working Current: 0.2-0.45A;
• Weight: 1500g;
• Dimension (Face Plate): 15x3.95x10(cm)
• Pack includes: One electric lock.

RFID Cards/Keyfobs :

There are 5pcs 125KHz RFID Proximity ID cards and 5pcs keyfobs, they can work with the product which has 125Khz RFID card reader.

• Operation Frequency: 125KHz
• Each card has an uniqe ID number.
• Perfect for attendance system, access control system, identification, low frequency tag card, etc.

• Water resistant
• Detecting distance: 3-10cm
• Compatible with all RFID ID card reader to gain access
• Each token pre-programmed with unique ID which is printed on it.

Exit button:

This exit button widely used in the door access control system.When you want to go out, you just need to press this Exit Button, then you can go out:

• Maximun Power Rating: 36 VDC 3A-5A output Support both NC Mode (Fail Safe Mode) & NO Mode (Fail Secure  Mode)
• Performance Testing: 1000000 times aging test
• Suitable For: Wooden Door, Metal Door, Glass Door, Fireproof Door, etc.

• Working voltage: DC12V
• Working current: 3A
• Faceplate Dimension: 85mmx85mm

Optional: if you need this remote control please buy from this link !

http:/store/product/Wireless-Remote-Control-Remote-Switch-For-Door-Lock-Access-Control-System/830381_1275240062.html

Remote Control:

This is a remote control device for Door Access Control System, after you connect it on your system, you can press the remote control to open the door remotely, the distance can reach up to 50 meters:

Connection Diagram:

Packing list:
